'D' PALE PALISADE FENCING

D pale steel palisade is mainly used in common and medium security fencing in UK, Australia and Africa. D profile offers less strength compared with W pale.

Materials

Galvanized;
HDG galvanized;
Power coated galvanized black or dark green.

D Pale Illustration

D pale with comparison of W section

D Pale Palisade Fencing Types and Target Countries

Galvanised Steel Palisade Fencing with D Section Triple Splayed Top Pales
Supplied with trellis, gates, posts, bolts, nuts and accessories
Finish: Heavy zinc coating

Palisade Fence shipped to Johannesburg South Africa
Includes all the uprights panels, D profile, in medium strength.
Height option: 2m and 2.4m high.
Supplied with flat coiled razor wire on top of the fence panels.

Border security products, for UK fencing company
Panel height 2.0m:
Pale thickness: 2.0mm; 2.5mm; 3.0mm
Panel height: 2.4m:
Pale thickness: 2.0mm; 2.5mm; 3.0mm

D Tripple Pointed Steel Palisade Fencing with Gates
Palisade fencing at 2.4m high
D pale tripple pointed
Pale thickness: 3.5mm
Supplied with matching gates at 2.4m height and 5m width

Standard 2.4 high galvanised steel palisade 3mm D section pale
For Liverpool UK
Supplied with 50x50x6 rails and 100x65mm posts

D Top Galvanized Palisades Fence with Complete Panel for self-assembly
Fence panel dimensions of 1.8m
3.0mm profile D triple pointed top and single pointed top

2.4metre height Palisade fencing in D Section offered to Melbourne, Australia.
4.0mm D section triple pointed pales, finished self colour

Steel Palisade Fencing with complete and related accessories for site assemble alongwith bolt fixing

Height 2.1 m

Type : D-PALE/ Triple Point Top

3 mm Steel thickness Hot depth Galvanized

With double leaves gate with central locking.

Height : 2.5 Mtr. Steel hot Galvanized.

Design to match the Palisade fencing.

Typical D Pale Palisade Fencing System - Kit Form - HDG Finish

Palisade Fencing Hot Dip Galvanized, Featuring D Section Triple Splayed Top Pales

Supplied with trellis, gates, posts, bolts, nuts and accessories, in kit form
Finish: Heavy zinc coating
2.40M Fence
‘D’ section triple splayed top pales
Fixed to 50mm x 50mm galvanised iron rails with 8mm ‘T’ bolts and anti-tamper shear nuts.
4 x end posts
1 x corner post.

Palisade fencing nominally 2.4m high with 102mmX45mm posts at a maximum of 2.75m centres suitably fabricated.
Angle rails 50mmX50mmX6mm thick. Rails drilled to accept mild steel corrugated triple pointed pales 67mmX3mm at 150mm centres.
All fencing to be galvanized.

Detailed Diagram
